16-Port Gigabit Ethernet Easy Smart PoE+ Switch with 1 Dedicated SFP port (180W)
16-Port Gigabit Ethernet Easy Smart PoE+ Switch with 1 Dedicated SFP port (180W)
GS116EP
1 / 6
Ports
- 16 Ports
Port Types
- 16 x 10/100/1000 RJ45 Copper Ports (Auto Uplink)
- 15 x PoE+ 802.3at Ports
- 1 x SFP fiber ports
PoE Budget
- Up to 180W
Details
GS116EP
Ports
- 16 Ports
Port Types
- 16 x 10/100/1000 RJ45 Copper Ports (Auto Uplink)
- 15 x PoE+ 802.3at Ports
- 1 x SFP fiber ports
PoE Budget
- Up to 180W
Details
Features
GIGABIT ETHERNET AND FIBER
15 ports provide Gigabit Ethernet connectivity to your devices and 1 SFP fiber port for long distance connections
EASY POE CONTROLS
Manage PoE prioritization, PoE power limit per port, PoE scheduling and more for advanced control over all PoE-powered devices
VERSATILE MOUNTING OPTIONS
Place your switch on your desktop or mount it to your wall with the hardware provided in the box. Silent operation makes this switch perfect for noise-sensitive environments
VLANS
Port-based and 802.1Q-based network separation into smaller groups for more secure and efficient use of network resources
FANLESS DESIGN
Silent operation makes this switch perfect for noise-sensitive environments
ENERGY EFFICIENT
Energy Efficient Ethernet (IEEE 802.3az) standard, which reduces energy consumption when there is light traffic on an active port or when there is no link or no activity detected
Technical Specifications
| Dimensions (W x D x H) | 286 x 101 x 27 mm (11.3 x 4.0 x 1.1 in) |
| Weight | 0.83kg (1.83 lb) |
| Speed | 1G |
| Number of Ports | 16 |
| Number of PoE+ Ports | 15 |
| Number of SFP Ports | 1 |
| PoE Power per Port | Up to 30 |
| PoE Budget | Up to 180W |
| Energy Efficient Ethernet Support (IEEE 802.3az) | Yes |
| Jumbo Frame Support | 10,000 bytes |
| MAC Table Size | 8K |
| Packet buffer size | 4.1MB |
| IEEE 802.1p QoS | Yes |
| Max Power Consumption | 198.7W |
| Operating Temperature | 0-40°C (32°F - 104°F) |
| MTBF (hours) | 784,742 hours (89 years) |
| FCC Class | Class B |
