24x10G/Multi-Gig PoE+ (576W base, up to 720W) and 4xSFP28 25G (XSM4328CV)
24x10G/Multi-Gig PoE+ (576W base, up to 720W) and 4xSFP28 25G (XSM4328CV)
XSM4328CV
1 / 8
Ports
- 28 Ports
Port Types
- 24 x 10G/Multi-Gig PoE+
- 4 x 25G SFP28
PoE budget
- 24 PoE+ (30W/port)
- 576W Base
- up to 720W Budget
Details
- 24 10G/Multi-Gig PoE+ ports with 4 25GBASE-X SFP28 uplinks
- 880W internal power supply providing 576W of PoE budget
- 1 slot for modular power supply (1+1 redundancy and/or EPS share)
- Any APS350Wv1, APS600Wv2, APS920Wv1, or APS2000Wv1 can be used
- The PoE budget can reach 720W, when the redundant PoE budget remains 576W
- Virtual Chassis stacking provides non-stop forwarding (NSF) and hitless failover
- Layer 3 feature set includes static, policy-based, and dynamic routing
- NETGEAR IGMP Plus™, AV User Interface, and Engage Controller speed up AV installations
- TAA compliant SKU is available. Contact your sales representative
Ports
- 28 Ports
Port Types
- 24 x 10G/Multi-Gig PoE+
- 4 x 25G SFP28
PoE budget
- 24 PoE+ (30W/port)
- 576W Base
- up to 720W Budget
Details
- 24 10G/Multi-Gig PoE+ ports with 4 25GBASE-X SFP28 uplinks
- 880W internal power supply providing 576W of PoE budget
- 1 slot for modular power supply (1+1 redundancy and/or EPS share)
- Any APS350Wv1, APS600Wv2, APS920Wv1, or APS2000Wv1 can be used
- The PoE budget can reach 720W, when the redundant PoE budget remains 576W
- Virtual Chassis stacking provides non-stop forwarding (NSF) and hitless failover
- Layer 3 feature set includes static, policy-based, and dynamic routing
- NETGEAR IGMP Plus™, AV User Interface, and Engage Controller speed up AV installations
- TAA compliant SKU is available. Contact your sales representative
POWER AND
THROUGHPUT
Edge to core stackable platform, from 1 Gigabit to 100 Gigabit, all within 15.75in (40cm) of depth.
Groundbreaking AV GUI
A simplified user interface makes it easy to assign configuration profiles to each port.
Multicast in an Instant
NETGEAR IGMP Plus™ provides multicast functionality right out of the box for most AV over IP applications.
Sleek, Quiet Design
Less fan noise, and mounting ears included for rack mounting.
Automatic Configuration
Auto-trunk and auto-LAG functionality auto connects with other M4350 (and M4250) switches.
Fast, Easy Configuration
for AV Pros
A streamlined interface using certified profiles with settings for any AV or broadcast application assigned to ports with just a few clicks.
Focus on the Event Not the Fan Noise
Most models have quiet mode which greatly reduces fan noise.
DESIGNED FOR
AV OVER IP
RIGHT OUT OF
THE BOX
With built-in NETGEAR IGMP Plus™, there's little-to-no setup required for flawless Video over IP delivery. Enable multicasting right out of the box.
PRO AV FAMILY COMPARISON
USE CASE
SWITCH STACKING
PoE CAPABLE
PORT SPEEDS
AVB SUPPORT
AV WEB UI / AV TEMPLATES
AV DESIGN
(FRONT LED'S & REAR CABLING)
M4350-XSM4328CV Technical Specifications
| M4350-24X4V (XSM4328CV) | 1 |
| Power cord(s) | 1 |
| Console USB Type-C cable | 1 |
| Rack-mounting standard bracket set | 1 |
| Set of longer brackets for recessed mounting | 1 |
| Rubber footpads for tabletop installation | 4 |
| Installation guide | 1 |
| Width | 440mm |
| Depth | 400mm |
| Height | 43.2mm |
| Weight | 6.58kg (14.51lb) |
| Primary Port Speed | 10 Gigabit / Multi-Gig |
| Number of Ports | 28 (24 x 10G/Multi-Gig PoE+, 4 x 25G SFP28) |
| PoE Ports / Budget | 24 PoE+ (30W/port), 576W Base, up to 720W Budget |
| IGMP Support | Enhanced (NETGEAR IGMP Plus™) |
| Jumbo Frame Support | Yes, up to 12kb |
| AVB Support | Yes, included |
| Acoustics | Quiet Mode 34.7dB@25ºC |
| Power Consumption | With PoE: 750.1W/2557.84Btu/hr Without PoE: 119.4W/374.92Btu/hr Standby without any port connection: 53.6W/168.3Btu/hr |
| PSU Compatible Models | APS350Wv1 APS600Wv2 APS920Wv1 APS2000Wv1 |
NETGEAR Engage Controller | Centralized application to configure all switches across your entire network. Lightweight and portable, you can run it from a USB thumb drive. |
