16-Port Gigabit Ethernet High-Power PoE+ Unmanaged Switch (260W)
16-Port Gigabit Ethernet High-Power PoE+ Unmanaged Switch (260W)
GS516PP
1 / 9
Ports
- 16 Ports
Port Types
- 16 x 10/100/1000Mbps Ports (Auto Uplink)
- 16 x 802.3at PoE+ Ports
PoE budget
- 260W
Details
GS516PP
Ports
- 16 Ports
Port Types
- 16 x 10/100/1000Mbps Ports (Auto Uplink)
- 16 x 802.3at PoE+ Ports
PoE budget
- 260W
Details
Features
ETHERNET PORT CONFIGURATION:
16 Gigabit ports
PLUG-AND-PLAY:
Simple set up with no software to install or configuration needed and zero maintenance
FULL PERFORMANCE:
Non-blocking switching architecture for maximum throughput at wire speed
POWER-OVER-ETHERNET:
16 PoE+ ports with 260W total power budget to power wireless AP, IP Cameras, IP Phones and much more.
POWER AUTO-BALANCE AND ALLOCATION
NETGEAR's unique PoE technology automatically balances the PoE power, delivering exactly what each device needs.
SILENT OPERATION:
The fanless design means zero added noise wherever its located, making it ideal for your home or business environment
ENERGY EFFICIENT:
Designed to optimize power usage lowering its cost to operate.
RUGGED METAL CASING
Durable desktop case for longevity
VERSATILE MOUNTING OPTIONS:
Supports desktop or rackmount placement, and includes all mounting hardware in the box
STANDARDS-BASED DESIGN
Ensure interoperability with any standards-based PDs
Instant Networking
Plug-and-play setup, get reliable and secure Internet connectivity immediately
Convenient Power-over-Ethernet
One cable for both power and connectivity. 16 PoE+ ports with 260W total power budget. 30W per port
Power Efficient
Each port uses only the power it needs thanks to auto-balancing
Designed for Zero-Noise Operation
Passively cooled fanless design to protect your business environment
Technical Specifications
Dimensions | 330 x 207 x 43 mm (12.99 in. x 8.15 in. x 1.7 in.) |
Weight | 2.30kg (5.07 lb) |
|
|
| Speed: | Gigabit |
| Number of Ports: | 16 |
| Number of PoE+ Ports: | 16 PoE+ ports, up to 30W per port |
| PoE Budget: | 260W |
| Energy Efficient Ethernet Support (IEEE 802.3az): | Yes |
| Jumbo Frame Support: | 9,216 bytes |
| MAC Table Size: | 8K |
| Packet buffer size: | 192 KB |
| IEEE 802.1p QoS: | Yes |
| Max Power Consumption: | 316.1W / 9.1W |
| Fans: | 2 |
| Operating Temperature: | 0° to 40°C (32° to 104°F) |
| MTBF (hours): | 2,415,333.9 hrs |
| FCC Class: | Class A |
Warranty : | This product is backed by NETGEAR limited lifetime hardware warranty. |
| | Click here for coverage, availability and terms and conditions. |
Support : | NETGEAR Support offers a customizable support experience based on your operational needs: |
|
|
|
|
| Support coverage in one, three, or five year contracts |
