  • 24 x 10G/Multi-Gigabit ports with 4 dedicated 10G SFP+ ports
  • Easy management with intuitive web-based Interface
  • Versatile placement options: desktop or rackmount
  • Optimized for low-noise operation
XS724EMv2 XS724EM-200EUS XS724EM-200EUS

10G/Multi-Gigabit Easy Smart Managed Switch (XS724EMv2) armor

24-Port 10G/Multi-Gigabit Ethernet Easy Smart Managed Switch with 4 Dedicated 10G SFP+ Ports armor

10G/Multi-Gigabit Easy Smart Managed Switch (XS724EMv2)

24-Port 10G/Multi-Gigabit Ethernet Easy Smart Managed Switch with 4 Dedicated 10G SFP+ Ports armor

Join Waitlist

Order now and we’ll ship as soon as it’s back in stock.

Get It By: Ships By:

Free Shipping & Returns

Join Waitlist

Notify me when this item comes back in stock

Please enter a valid e-mail address.

You are already on the list. We’ll notify you shortly.

Successfully registered.

  • 24 x 10G/Multi-Gigabit ports with 4 dedicated 10G SFP+ ports
  • Easy management with intuitive web-based Interface
  • Versatile placement options: desktop or rackmount
  • Optimized for low-noise operation

Why Multi-Gigabit?

Maximize network performance by giving your devices the speed they need automatically: 100M /1G / 2.5G / 5G or 10G.

LEARN MORE

Features

MULTI-GIGABIT CONNECTIONS
Each port automatically detects and provides the exact speed needed (1G/2.5G/5G/10G). Upgrade your current network without upgrading your existing cabling, thanks to Multi-Gigabit you will be able to run 5G and 2.5G over connections up to 100m.
SFP+ FIBER UPLINKS
10G SFP+ ports provide flexible fiber connectivity options for core switch uplinks with backward compatibility to Gigabit fiber networks.
WHISPER-QUIET ACTIVE COOLING & FLEXIBLE FORM FACTOR
Active fan design operates below office ambient noise levels while maintaining optimal performance at temperatures up to 50°C, with Rack-mount or Desktop deployment options for versatile placement in any network environment.
AUTO-VLAN
Automatic VLAN assignment for voice, video, WiFi, and camera traffic providing instant network segmentation and optimization for critical business applications.
COMPREHENSIVE QOS CONTROLS
Port-based, IEEE 802.1p, and DSCP-based traffic prioritization with rate limiting ensures optimal performance for mission-critical applications like voice and video.
LINK AGGREGATION & REDUNDANCY
Static LAG and LACP support enables bandwidth aggregation and failover protection with up to 8 members per LAG for enhanced network reliability.

Technical Specifications

Tech_Specs_XS724EMv2_Desktop Tech_Specs_XS724EMv2_Mobile

  • Dimensions (W x D x H)
    440 x 204 x 43 mm (17.3 x 8 x 1.7 in)
  • Weight
    3.9kg (8.6lb)
  • Speed
    1G/2.5G/5G/10G
  • Number of Ports

    100M/1G/2.5G/5G/10G RJ-45 copper ports: 24

    SFP+ Ports : 4 (supports 2x10G copper modules)

  • Form Factor
    Desktop/Rackmount
  • Bandwidth
    560 Gbps
  • Energy Efficient Ethernet Support (IEEE 802.3az)
    Yes
  • Jumbo Frame Support
    12,288 bytes
  • MAC Table Size
    32K
  • Packet buffer size
    8MB
  • IEEE 802.1p QoS
    Yes
  • VLAN (# supported)
    64
  • Number of LAGs & number of members
    12 LAG with max 8 members in each LAG
  • Supported multicast groups
    256
  • Max Power Consumption
    139W
  • Fans
    3
  • Acoustic noise level @ 25° C (dBA)
    35.3 dBA
  • LEDs
    Power, Speed, Fan, Link/Activity
  • Operating Temperature
    0-50°C (32°F - 122°F)
  • MTBF (hours)
    161,283 hrs (18.4 years)
  • FCC Class
    Class A
  • This product is backed by a NETGEAR limited lifetime hardware warranty (depending on region). Click here for coverage, availability and terms and conditions.

    Next Business Day Hardware Replacement for duration of warranty (depending on region). Click here for coverage, availability and terms and conditions.

  • ProSUPPORT 24x7 Advanced Technical Support via phone for 90 days (Remote diagnostics performed by our technical experts for prompt resolution of technical issues). ProSUPPORT coverage can be extended by purchasing 1, 3, or 5-year contracts.

    ProSUPPORT Lifetime 24x7 Advanced Technical Support via chat.
