48-Port Gigabit Ethernet Unmanaged PoE+ Switch (380W)
48-Port Gigabit Ethernet Unmanaged PoE+ Switch (380W)
GS748PP
1 / 5
Ports
- 48 Ports
Port Types
- 48 x 10/100/1000 Mbps Ports (Auto Uplink), 24 x 802.3af PoE Ports, 24 x 802.3at PoE+ Ports
PoE Budget
- 380 W
Details
GS748PP
Ports
- 48 Ports
Port Types
- 48 x 10/100/1000 Mbps Ports (Auto Uplink), 24 x 802.3af PoE Ports, 24 x 802.3at PoE+ Ports
PoE Budget
- 380 W
Details
Features
POWER-OVER-ETHERNET
24 PoE+ ports delivering up to 30W per port with a 380W total power budget for wireless APs, IP Cameras, IP Phones and much more. Dynamic PoE maximizes usage of PoE budget.
PLUG-AND-PLAY
Simple set up with no software to install or configuration needed
NON-BLOCKING SWITCHING
Non-blocking switching architecture for maximum throughput at wire speed
DYNAMIC FANS
Optimal balance between noise and performance.
VERSATILE MOUNTING OPTIONS
Install your switch on your desktop or mount it to your rack with the hardware provided in the box
ENERGY EFFICIENT
Energy Efficient Ethernet (IEEE 802.3az) standard, which reduces energy consumption when there is light traffic on an active port or when there is no link or no activity detected
Product Specifications
Dimensions (W x D x H) : | 440 x 310 x 43 mm (17.9 x 12.2 x 1.7 in) |
Weight : | 4.6 kg (10.1 lb) |
Speed: | 1G |
Number of Ports: | 48 |
Number of PoE+ Ports: | 24 |
PoE Power per Port: | Up to 30W |
PoE Budget: | 380W |
Energy Efficient Ethernet Support (IEEE 802.3az): | Yes |
Jumbo Frame Support: | 12,288 bytes |
MAC Table Size: | 8K |
Packet buffer size: | 1.5MB |
IEEE 802.1p QoS: | Yes |
Max Power Consumption: | 410W |
Fans: | 2 |
Operating Temperature: | 0-50°C (32°F - 122°F) |
MTBF (hours): | 570,972 hours (65 years) |
FCC Class: | Class A |
Warranty : | This product is backed by NETGEAR limited lifetime hardware warranty. |
| | Click here for coverage, availability and terms and conditions. |
Support : | NETGEAR Support offers a customizable support experience based on your operational needs: |
| |
|
| |
|
| Support coverage in one, three, or five year contracts |
