24-Port Gigabit Ethernet PoE+ Smart Managed Essentials Switch with 2 Dedicated SFP Ports (190W)
24-Port Gigabit Ethernet PoE+ Smart Managed Essentials Switch with 2 Dedicated SFP Ports (190W)
GS324TPv2
1 / 6
Ports
- 26 Ports
Port Types
- 24 x Gigabit Ethernet PoE+ ports
- 2 x SFP fiber uplink ports (dedicated)
PoE Budget
- 190W
Details
- Advanced L2 smart switching features
- Easy-to-use web browser-based management GUI
- Advanced per-port PoE controls
- Quiet desktop or rackmount placement
- Energy Efficient Ethernet (IEEE 802.3az) to maximize power savings
GS324TPv2
Ports
- 26 Ports
Port Types
- 24 x Gigabit Ethernet PoE+ ports
- 2 x SFP fiber uplink ports (dedicated)
PoE Budget
- 190W
Details
- Advanced L2 smart switching features
- Easy-to-use web browser-based management GUI
- Advanced per-port PoE controls
- Quiet desktop or rackmount placement
- Energy Efficient Ethernet (IEEE 802.3az) to maximize power savings
Features
HIGH-DENSITY CONNECTIVITY
Provides 24 Gigabit Ethernet PoE+ ports for connecting numerous devices, plus 2 dedicated SFP ports for high-speed fiber uplinks to your core network
ROBUST POE+ POWER
Delivers a 190W total PoE budget to power a dense deployment of devices like VoIP phones, IP surveillance cameras, and wireless access points
ADVANCED SWITCHING CAPABILITIES
Features L2 management, including VLANs, QoS, LACP, ACL and STP for optimized network performance and security.
INTUITIVE WEB MANAGEMENT
Configure and manage your network with a straightforward, user-friendly web browser-based GUI that simplifies administration.
BUILT FOR RELIABILITY
Includes a 3-year hardware warranty, ensuring dependable performance for growing business networks.
Technical Specifications
NETGEAR 24-Port Gigabit Ethernet PoE+ Smart Managed Essentials Switch
Power cord varies by region
Rack-mount kit and rubber feet
Width | 440mm |
Depth | 257mm |
Height | 43mm |
Weight | 3.53kg (7.78lb) |
10/100Mbps ports | N/A |
Gigabit ports | 24 |
SFP ports | 2 |
Number of PoE ports | 24 |
PoE+ (802.3at) | 24 (30W per port) |
Total PoE Power budget (Watts) | 190W |
Max MAC entries | 8K |
Buffer size | 1.5MB |
VLAN (Number Supported) | 64 |
VLAN routing | Yes |
Dynamic VLAN assignment | Yes |
Host ARP table | 512 |
EEE | Yes |
DoS Prevention | Yes |
Internal/External | Internal 100-240VAC, 50-60Hz, 4A |
Max consumption (Watts) | 208W |
FAN | 2 |
Acoustic Noise Level @25C (dBA) | 26.1 |
Operating Temperature | 0° to 50° C |
MTBF | 1,784,610 hours (203.7 years) |
NETGEAR Web GUI
Configure your network effortlessly with the user friendly NETGEAR web GUI, no IT expert required.
