8-port, 5-speed Unmanaged Switch 10-Gigabit/Multi-Gigabit
8-port, 5-speed Unmanaged Switch 10-Gigabit/Multi-Gigabit
XS508M
1 / 8
Ports
- 8 Ports
Port Types
- 7 x 100M/1G/2.5G/5G/10G RJ-45 copper ports
- 1 x 10G/1G SFP+ and Copper (combo)
Details
XS508M
Ports
- 8 Ports
Port Types
- 7 x 100M/1G/2.5G/5G/10G RJ-45 copper ports
- 1 x 10G/1G SFP+ and Copper (combo)
Details
Features and benefits
Plug-and-play
Automatic connectivity to your router or modem of 4 or 7 additional wired connections. No need for an IT expert!
All speeds welcome
Expand your network instantly, and give your devices either 100Mb, 1, 2.5, 5 or 10-Gigabit, automatically
Mounting flexibility
Small and silent desktop or rackmount form factor for quiet operation – Adapts to your needs and configuration in any environment
Industry leading support
ProSAFE LIFETIME Warranty, Next Business Day replacement and 24/7 chat with a NETGEAR expert
Energy efficient
Switches automatically adjust power consumption according to the link status and cable length.
Product Specifications
Dimensions (W x D x H) | 328 x 169 x 43.2 mm (12.91 x 6.65 x 1.7 in) |
| Weight | 1.49 Kg (3.28lb) |
100M/1G/2.5G/5G/10G RJ-45 copper ports | 7 |
10G SFP+ ports | 1 x 10G/1G SFP+ and Copper (combo) |
Form Factor | Desktop/Rackmount |
Packet buffer memory | 128KB |
Bandwidth | 160Gbps |
MAC Address database size | 2 K |
Number of priority queues | 8 |
Jumbo frame support | Up to 9K packet size |
Fan(s) | 1 Low-Noise Active Fan |
IEEE 802.3az (Energy Efficient Ethernet) | Yes |
Max power consumption (Watts) | 39W |
LEDs | Power, Fan, Speed, Link/Activity |
Acoustic noise level @ 25° C (dBA) | 28dB |
Operating temperature | 0° to 40° C |
MTBF (@ 25° C) | 22.5dBA |
Electromagnetic compliance (A or B) | B |
| | This product is backed by NETGEAR limited lifetime hardware warranty. |
| | Click here for coverage, availability and terms and conditions. |
Support | NETGEAR Support offers a customizable support experience based on your operational needs: |
| |
|
| |
|
| Support coverage in one, three, or five year contracts |
| | XS508M 10-Gigabit/Multi-Gigabit Ethernet Unmanaged Switch |
| | Power cord (localized to country of sale) |
| | Rack-mounting kit |
| | Quick install guide |
