5-Port Gigabit Ethernet Unmanaged PoE+ Essentials Switch (63W)
5-Port Gigabit Ethernet Unmanaged PoE+ Essentials Switch (63W)
GS305Pv3
1 / 6
Ports
- 5 Ports
Port Types
- 5 x 10/100/1000Mbps Ports (Auto Uplink)
- 4 x 802.3af PoE Ports
- 4 x 802.3at PoE+ Ports
PoE Budget
- Up to 63W Total
Details
GS305Pv3
Ports
- 5 Ports
Port Types
- 5 x 10/100/1000Mbps Ports (Auto Uplink)
- 4 x 802.3af PoE Ports
- 4 x 802.3at PoE+ Ports
PoE Budget
- Up to 63W Total
Details
Features
ETHERNET PORT CONFIGURATION
5 Gigabit ports
PLUG-AND-PLAY
Simple set up with no software to install or configuration needed and zero maintenance
FULL PERFORMANCE
Non-blocking switching architecture for maximum throughput at wire speed
POWER-OVER-ETHERNET
4 PoE+ ports with 63W total power budget to power wireless AP, IP Cameras, IP Phones and much more
PoE POWER AUTO-BALANCE AND ALLOCATION
NETGEAR's unique PoE technology automatically balances the PoE power at the most granular level on each port, depending on the device needs.
SILENT OPERATION
The fanless design means zero added noise wherever its located, making it ideal for noise-sensitive environments
ENERGY EFFICIENT
Designed to optimize power usage lowering its cost to operate.
VERSATILE MOUNTING OPTIONS
Supports desktop and wall placement. Includes wall mount kit in the box
STANDARDS-BASED DESIGN
Ensure interoperability with any standards-based PDs
Technical Specifications
Dimensions (W x D x H) | 158 x 101 x 27 mm (6.2 x 4.0 x 1.1 in) |
Weight | 0.40kg (0.88 lb) |
Speed | Gigabit |
Number of Ports | 5 |
| | 4 PoE+ @ 30W each until budget is met |
PoE budget | Up to 63W Total |
Energy Efficient Ethernet Support (IEEE 802.3az) | Yes |
Jumbo frame support | 9,216 bytes |
Queue WRR Ratio | 1:2:4:8 |
MAC table size | 2k |
Packet buffer size | 128KB |
IEEE 802.1p QoS | Yes |
Power Consumption (Max/Standby) | 66.78W/1.02W |
Operating Temperature | 0-40°C (32°F - 104°F) |
MTBF (hours) | 4,113,947 hrs (469.32 years) |
FCC Class | Class B |
Fans | 0 |
Acoustic Noise Level @25C | Fanless |
Warranty | This product is backed by NETGEAR limited lifetime hardware warranty. |
| Click here for coverage, availability and terms and conditions. |
Support | NETGEAR Support offers a customizable support experience based on your operational needs: |
| |
|
|
|
| Support coverage in one, three, or five year contracts |
